K SERIES HELICAL-BEVEL GEAR UNITS

Name: K SERIES HELICAL-BEVEL GEAR UNITS
Brand: TAIXING
Rating: 5.0 (74 reviews)


Availability:

Quantity:



Inquire Add to Basket

K SERIES HELICAL-BEVEL GEAR UNITS OVERVIEW
Brand Name TAIXING
Product Name K Series electric Helical Bevel Gear Motor
Gear type Helical - bevel
Color Blue or Grey (other color according to RAL Standard)
Standard ISO9001:2008/CE
Grade DIN6
Application Industrial application

Model:
K157
Brand:
TAIXING

K Series Spiral Bevel Gear Reducer S Series Helical Worm Gearbox PARALLEL SHAFT GEARBOX for Crane K Series Helical-bevel Gearbox HELICAL BEVEL GEARMOTOR

Product Description

Features-THREE STAGE	-Their high level of efficiency makes them energy –saving angular drives -High-endurance gearing makes for high-torque, wear-free drives -Long maintenance-free service life -Also available with reduced backlash -Available design -Foot- or flange – mounted design -B5 or B14 flange -Solid or hollow shaft -Hollow shaft with keyed connection, shrink disk, splining, or torque arm
Features-TWO STAGES	-Can be used in all industries and applications, e.g. in lifts or conveyor applications - Low loss, two stage design - Gear with infinite fatigue strength, which means the drive is almost wear-free -Can be combined with all motor from BAFFERO -Energy efficiency: - low energy consumption -Gear unit efficiency allows smaller motor-compact design -Wide range of designs ensures an optimum connection to be customer machine even in critical mounting situations
Gear unit ratio	5.36~179.37
Gear unit ratio-compound gear unit	94-32625
Max. output torque	50000N.m
Output speed	0.1-270 r/min
Motor power	0.18~200KW

THE DESIGNS OF K SERIES HELICAL BEVEL GEARMOTOR

K….Y…

Foot-mounted helical-bevel gear motor with solid shaft

KAB…Y…

Foot-mounted helical-bevel gear motor with hollow shaft

KA….Y…

Helical-bevel gear motor with hollow shaft

KF…Y…

Flange-mounted helical-bevel gear motor with solid shaft

KAF…Y…

Flange-mounted helical –bevel gear motor with hollow shaft

KAT…Y…

Torque-arm mounted helical-bevel gear motor with hollow shaft

K(KF.KA.KAF.KAB.KAZ)S …

Shaft input helical-bevel gear motor

KA(K..KF,.KAF..KAB.KAZ.).RF..Y..

Combination helical-bevel gear motor

KA(K.KF,KAF,KAB,KAZ) S…RF..

Shaft input combination helical-bevel gear motor

The company has the world's advanced processing machine tools and testing equipment, strong technical force, to provide users with high-quality products.
